210kN insulators UG210B170 double-umbrella Suspension Electrical Glass Insulator
Short Description:
The product consists of an iron cap, tempered glass parts, and steel feet, and is integrated with cement adhesive. This product adopts the most advanced cylindrical head structure internationally, characterized by small head size, light weight, high strength, and large creepage distance. Can save metal materials and reduce line costs. To meet the needs of live working, traditional domestic structural shapes are used on the brim of the hat.
Phone
whatsapp
Email
| 210kN double-umbrella disc suspension glass insulator UG210B170/450D 20R Jiangxi Huayao Electric Co., Ltd., which is located in Shangbu Town Industrial Park, Luxi County, Pingxiang City, Jiangxi Province,China is one of the leading glass insulator manufacturers in China. The registered capital of the company is 120 million yuan, covering an area of 47 acres, with a total construction area of 17200 square meters and more than 150 employees. |
 |
Huayao advantage products are glass insulators with a capacity of 40kN-550kN, which can meet the requirements of 10kV-500kV ultra-high voltage and extra high voltage transmission and transformation lines.
Huayao strictly complies with GB, ANSI, BS, DIN, AS, IEC standard designs, applicable to power transmission lines and substations.Huayao has established a production line for ultra-high voltage tempered glass insulators with advanced production technology by introducing world-class production and testing equipment from Germany, Italy, and other countries. It has the ability to produce over 6 million pieces of AC and DC glass insulators annually.
Main types of glass insulator：
Glass insulator is including standard type, pollution resistant type, DC type, spherical type, aerodynamic type, ground wire type, and contact network for electrified railways
Jiangxi Huayao electric Co.,ltd produce standard type glass insulator 40-550Kn, Pollution resistant type 70-400Kn, mutil-umbrella type 120-330kN, Glass insulator aerodynamic type 120-300kN, ground wire type.
| Main technical parameters (GB and IEC) of double-umbrella disk suspension type glass insulator | |||||||||||
| Type | Diameter D (mm) | spacing H (mm) | creepage distance L(mm) | size of coupling (mm) | Mechnical failing load (kN) | Mechnical routine test (kN) | Power frequency withstand voltage DRY (kV) | Power frequency withstand voltage WET (kV) | lighting impulse withstand voltage (kV) | Min power frequency puncture voltage (kV) | Net weight per unit (kg) |
| UG70B146/450D 16R | 280 | 146 | 450 | 16 | 70 | 35 | 80 | 45 | 120 | 130 | 6.30 |
| UG100B146/450D 16R | 280 | 146 | 450 | 16 | 100 | 50 | 80 | 45 | 120 | 130 | 6.30 |
| UG120B146/450D 16R | 280 | 146 | 450 | 16 | 120 | 60 | 80 | 45 | 120 | 130 | 6.30 |
| UG160B170450D 20R | 300 | 170 | 450 | 20 | 160 | 80 | 85 | 45 | 130 | 130 | 8.40 |
| UG210B170/450D 20R | 300 | 170 | 450 | 20 | 210 | 105 | 85 | 45 | 130 | 130 | 9.00 |
| UG300B195/480D 24R | 330 | 195 | 480 | 24 | 300 | 150 | 85 | 50 | 130 | 130 | 13.00 |
| Product name: Glass insulator | Model number:UG210B170/450D 20R |
| Material: fiberglass | Application: high voltage |
| Rated voltage: 33kV | Product name: high voltage insulator |
| Brand name: Huayao | Usage：Transmission lines |
| Application: insulation | Rated voltage: 12kV |
| Place of origin: Jiangxi, China | Certificate:ISO9001 |
| Standard: IEC60383 | Color: Jade green |
Product Details
| 210kN double-umbrella disc suspension glass insulator U210B170/450D 20R Place of Origin: China Brand name: HUAYAO Certification: ISO9001 Daily output: 10000 pieces Payment & Shipping Minimum Order Quantity: 10 pieces Packaging Details: normal export packaging Supply Ability: 50000pcs Delivery Port: Ningbo,Shanghai Payment term: TT, L/C, FCA |
 |
Quick Detail
| Glass Double umbrella disc Suspension Insulators U210B170/450D 20R Dimensions Diameter (D): 300mm Spacing (H): 170mm Creepage Distance: 450mm Coupling Size: 20mm Mechanical Values Mechanical Failing Load: 210kN Tension Proof: 105kN Electrical Values Dry Power-frequency Withstand Voltage: 85kV Wet Power-frequency Withstand Voltage: 45kV Dry Lightning Impulse Withstand Voltage: 130kV Puncture Withstand Voltage: 130kV Radio Influence Voltage Data Test Voltage RMS to Ground: 10kV Maximum RIV at 1000 kHz: 50μV Packing and Shipping Data Net Weight, Approximate: 9.0kg |
 |
Performance advantages of double-umbrella disc suspension glass insulator
Good anti-pollution performance: the double umbrella structure makes the pollution distribution on the surface of the insulator more uniform, and it is not easy to form local pollution accumulation, thus improving the pollution-resistant lightning pressure of the insulator, and effectively reducing the occurrence of pollution flashover accidents in areas with serious pollution.High mechanical strength: it can bear the vertical load and horizontal tension of the conductor, as well as the additional load generated by severe weather conditions such as strong wind, rainstorm, ice and snow, etc., to ensure that the insulator will not be damaged by mechanical stress during long-term operation.
Long service life: Due to its good pollution resistance and mechanical strength, double umbrella insulators can be used for a long time under normal operating conditions, reducing the frequency of insulator replacement and reducing line maintenance costs.
Test report of Jiangxi huayao electric Co.,ltd glass insulator
Jiangxi Huayao electric Co.,ltd provide test report from third party such as Xi'an High Voltage Apparatus Research Institute Co., Ltd. (XIHARI) ,National ceramic product quality inspection and test center.Pre-shipment inspection from third party such as INTERTEK, SGS, BV or customer themselves.
Standard of glass insulator:
The tests have been performed in accordance with:
GB/T1001.1-2021 Insulators for overhead lines with a norminal voltage above 1000V Part1: Ceramic or glass insulator units for a.c. systems Definitions, test methods and acceptance criteria (IEC 60383-1:2021 MOD)
GB/7253-2019 Insulator for overhead lines with a nominal voltage above 1000V-Ceramic or glass insulator units for a.c. systems-Characteristics of insulator units of cap and pin type (IEC 60305:2021 MOD)
IEC 60383-1:2023 Insulators for overhead lines with a norminal voltage above 1000V
IEC 60120:2020 Dimensions of ball and socket couplings of string insulator units
Jiangxi Huayao electric Co.,ltd strictly compliance with above standard. We do the factory test report as above standard.
We always do following test for each products:
1. Verification of the Dimensions
2. Verifications of Displacements
3. Locking system test
4. Galvanized test
Galvanized layer Specified Value
Cap ：Minimum values of single sample 70 m；
Average values of all samples 85 m
Pin：Minimum values of single sample 70 m；
Average values of all samples 85 m
5.Thermal shock test
Specified values
The test sample is heated to above the temperature of more than100 K, and then immersed in temperature which does not exceed 50C in water for more than 2 min.
Test condition pieces glass insulators are heated to the temperature of 130C, the temperature of cold water25C, temperature difference 105K, keep in cold water for 2 min.
Test result Samples are OK.
6.Mechanical Failing Load Test
Specified Values SFL=160kN, Mechanical load 165kN no mechanical failing
7.Power frequency puncture withstand test
The results of power frequency puncture withstand test please check the following table, no puncture.
Package of the glass insulator：
Standard export wooden cases Non fumigation wooden box
